GVW Driving Type 4x2 |
||
Model |
CLW |
|
Cab |
Isuzu FVR one and half row cab, tilted |
|
Engine(Hp) |
240 |
|
Power(Kw) |
177 |
|
Wheelbase |
5550 |
|
Front/Rear Suspension |
1335/2880 |
|
Steering |
Power steering |
|
Approach/departure angle |
26/10 |
|
Wheels & tire |
11.00R20 |
|
Tire number |
6+1 |
|
Body Dimensions(mm) |
7180×2250×2400 |
|
Loading capacity(kg) |
/ |
|
RHD or LHD |
LHD |
|
Overall Dimensions(mm) |
9800×2550×3950 |
|
Curb weight (Kg) |
7670 |
|
Engine |
Model |
6HK1-TCL |
Horsepower |
240 |
|
Maximum output Kw |
177 |
|
Maximum torque N.m |
|
|
Type |
6 cylinders,4 valve,4-stroke, diesel engine |
|
Displacement |
7.79L |
|
ISUZU brand, Euro 5 |
||
Driving passenger |
3 |
|
Transmission |
ISUZU MLD 6 speed forward and one reverse, manual |
|
Front Axle |
6.3T |
|
Rear Axle |
13T |
|
Brake System |
air brake |
|
Color and LOGO |
customized |
|
Electric system |
24V |
|
Refrigerator unit |
-5°or -15°or -18°selective |
|
Standard configuration |
van body(inner glass steel, outer glass steel,8cm polyurethane foam insulation),stainless steel locks, stainless steel door frame, with overhead light and anti collision device, domestic refrigeration unit |
|
Delivery date |
Within 40 days after receipt advance |
|
Packing |
Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. |
