GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

130

Power(Kw)

96

Wheelbase

3815

Front/Rear Suspension

1015/2150,1110/2015

Steering

Power steering

Approach/departure angle

24/16,19/13

Wheels & tire

7.0R16

Tire number

6+1

Body Dimensions(mm)

5000×1900×1800

Loading capacity(kg)

/

RHD or LHD

LHD

Overall Dimensions(mm)

7000×2150×3100

Curb weight (Kg)

3870

Engine

Model

4KH1CN5HS

Horsepower

130

Maximum output Kw

96

Maximum torque N.m

290

Type

4 cylinders, in-line, 4-stroke,diesel engine

Displacement

2.999L

ISUZU brand, Euro 5

Driving passenger

2,3

Transmission

ISUZU MSB 5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.8T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Refrigerator unit

-5°or -15°or -18°selective

Standard configuration

van body(inner glass steel, outer glass steel,8cm polyurethane foam insulation),stainless steel locks, stainless steel door frame, with overhead light and anti collision device, domestic refrigeration unit

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
