GVW                                                   Driving Type 8x4

Model

CLW

Cab

D310 standard flat roof a row and a half deluxe cab(with sleeping berth),air conditioner, electric glass, hydraulic mechanical flip, channel type instrument panel, central lock, allowable 3 passengers

Engine(Hp)

340

Power(Kw)

250

Wheelbase

1950+4200+1350

Front/Rear Suspension

1500/2985

Steering

Power steering

Approach/departure angle

22/12

Wheels & tire

11.00R20

Tire number

12+1

Body Dimensions(mm)

9400×2400×2450

Loading capacity(kg)

/

RHD or LHD

optional

Overall Dimensions(mm)

12000×2600×3990

Curb weight (Kg)

12900

Engine

Model

L340 30

Horsepower

340

Maximum output Kw

250

Maximum torque N.m

1350

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

8.900L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

FAST 12 speed forward and 2 reverse, manual

Front Axle

6.5T x2

Rear Axle

12T x2

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Refrigerator unit

-5°or -15°or -18°selective

Standard configuration

van body(inner glass steel, outer glass steel,8cm polyurethane foam insulation),stainless steel locks, stainless steel door frame, with overhead light and anti collision device, domestic refrigeration unit

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
