GVW                                                    Driving Type 6x4

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers

Engine(Hp)

210

Power(Kw)

155

Wheelbase

4350+1300

Front/Rear Suspension

1430/2750

Steering

Power steering

Approach/departure angle

19/10

Wheels & tire

10.00R20

Tire number

10+1

Compactor capacity(m3)

16

RHD or LHD

optional

Overall Dimensions(mm)

10100×2500×3250

Curb weight (Kg)

13700

Engine

Model

B210 33

Horsepower

210

Maximum output Kw

155

Maximum torque N.m

720

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5.9L

Cummins brand, Euro 3

Driving passenger

3

Transmission

Fast 9 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Compactor body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control ,PLC control.

Selective equipment

Rear side arm swing type instrument

compactor

capacity

16m3

Loading cycle

15-30s

Unloading cycle

20-30s

Compressed proportion

1:3/1:2

Garbage bin turning over instrument

available

Different instrument selective

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
