GVW                                                  Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

57

Power(Kw)

42

Wheelbase

3360

Front/Rear Suspension

1085/1545

Steering

Power steering

Approach/departure angle

23/19

Wheels & tire

6.5-16

Tire number

6+1

Body Dimensions(mm)

4080×1900×1800

Loading capacity(T)

/3

RHD or LHD

LHD

Overall Dimensions(mm)

6000×2100×3000

Curb weight (Kg)

3800

Engine

Model

N490QB

Horsepower

57

Maximum output Kw

42

Maximum torque N.m

140

Type

4 cylinders, in-line, 4-stroke,diesel engine

Displacement

2.544L

Quanchai brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2.4T

Rear Axle

4T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Refrigerator unit

-5°or -15°or -18°selective

Standard configuration

van body(inner glass steel, outer glass steel,8cm polyurethane foam insulation),stainless steel locks, stainless steel door frame, with overhead light and anti collision device, domestic refrigeration unit

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
