GVW                                                  Driving Type 6x6

Model

CLW

Cab

A row and a half cab(with sleeping berth),allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

3500+1250

Front/Rear Suspension

1250/1625 (mm)

Steering

Power steering

Approach/departure angle

10/12

Wheels & tire

12.5R20

Tire number

6+1

Tank Dimensions(mm)

4800/2040/1200

Cubage (m3)

10

Steel thickness of tank(mm)

/

RHD or LHD

LHD

Overall Dimensions(mm)

8000×2500×3000

Curb weight (Kg)

7660

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5900ml

Cummins, Euro 3

Driving passenger

3

Transmission

Fast 8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

5Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Standard configuration

oil pump, tool box, manhole sub-sea valve, climbing ladder, fire extinguisher, oil hose.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
