GVW                                                  Driving Type 8x4

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

336

Power(Kw)

247

Wheelbase

1800+4600+1350

Front/Rear Suspension

1576/2650 (mm)

Steering

Power steering

Approach/departure angle

15/15

Wheels & tire

295/80R22.5

Tire number

12+1

Tank Dimensions(mm)

8900×2500×1800

Cubage (m3)

25-30

Steel thickness of tank(mm)

6

RHD or LHD

optional

Overall Dimensions(mm)

11900×2500×3400

Curb weight (Kg)

14900

Engine

Model

WD615.69

Horsepower

336

Maximum output Kw

247

Maximum torque N.m

1350

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9.726L

CNHTC diesel engine, Euro 2

Driving passenger

2,3

Transmission

HW19710 , 10speed forward and 2 reverse, manual

Front Axle

7Tx2

Rear Axle

16T x2

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel, stainless steel, aluminum, etc. alloy, etc.

Standard configuration

oil pump, flow valves, tool box, manhole, climbing ladder, fire extinguisher, oil hose.

Optional configuration

 flow meter, refueling machine, European standard manhole, pneumatic valve, AIP valve, anti overflow sensor plug, oil and gas recovery system, divided into several compartments.

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
