GVW                                                    Driving Type 4x2

Model

CLW

Cab

Howo light duty cab ,one row cab, tilted

Engine(Hp)

110

Power(Kw)

81

Wheelbase

3360

Front/Rear Suspension

1160/2070

Steering

Power steering

Approach/departure angle

24/23

Wheels & tire

7.0R16

Tire number

6+1

Compactor capacity(m3)

5

RHD or LHD

optional

Overall Dimensions(mm)

6615×2100×2550

Curb weight (Kg)

5165

Engine

Model

YN4100QBZL

Horsepower

110

Maximum output Kw

81

Maximum torque N.m

285

Type

4cylinders, in-line,4-stroke, diesel engine

Displacement

3.298L

Yunnei brand, Euro 2

Driving passenger

2,3

Transmission

WLY 5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

3.5T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Standard configuration

Compactor body, sub frame, rear lifting part, loading bunker, pushing-out plate, hydraulic system, pressing system, sewage tank, climbing ladder, pneumatic control ,PLC control.

Selective equipment

Rear side arm swing type turning over instrument

compactor

capacity

5m3

Loading cycle

15-30s

Unloading cycle

20-30s

Compressed proportion

1:3/1:2

Garbage bin turning over instrument

available

Different instrument selective

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
