GVW                                                Driving Type 6x4

Model

CLW

Cab

D310 standard flat roof a row and a half deluxe cab(with sleeping berth), air conditioner, electric glass, hydraulic mechanical flip, channel type instrument panel, central lock, allowable 3 passengers

Engine(Hp)

260

Power(Kw)

191

Wheelbase

4350+1300

Front/Rear Suspension

1460/2650(mm)

Steering

Power steering

Approach/departure angle

16/12

Wheels & tire

10.00R20

Tire number

10+1

Tank Dimensions(mm)

Cubage (m3)

20

Steel thickness of tank(mm)

5

RHD or LHD

optional

Overall Dimensions(mm)

9760×2485×3300

Curb weight (Kg)

12220

Engine

Model

C260 33

Horsepower

260

Maximum output Kw

191

Maximum torque N.m

1090

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

8300ml

Cummins, Euro 3

Driving passenger

2,3

Transmission

FAST 10 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10Tx2

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel, stainless steel, aluminum, etc. alloy, etc.

Standard configuration

oil pump,flow valves, tool box, manhole, climbing ladder, fire extinguisher, oil hose.

Optional configuration

 flow meter, oiling machine, European standard manhole, pneumatic valve, AIP valve, anti overflow sensor plug, oil and gas recovery system, divided into several compartments.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
