GVW                                                  Driving Type 4x2

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),,hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers

Engine(Hp)

190

Power(Kw)

140

Wheelbase

4500,4700

Front/Rear Suspension

1430/2400 (mm)

Steering

Power steering

Approach/departure angle

20/13

Wheels & tire

10.00-20,10.00R20

Tire number

6+1

Tank Dimensions(mm)

Cubage (m3)

15

Steel thickness of tank(mm)

5

RHD or LHD

optional

Overall Dimensions(mm)

8500×2500×3200

Curb weight (Kg)

7200

Engine

Model

B190 33

Horsepower

190

Maximum output Kw

140

Maximum torque N.m

640

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5900ml

Cummins, Euro 3

Driving passenger

2,3

Transmission

FAST 8 speed forward and one reverse, manual

Front Axle

5T

Rear Axle

10T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel, stainless steel, aluminum, etc. alloy, etc.

Standard configuration

oil pump,flow valves, tool box, manhole, climbing ladder, fire extinguisher, oil hose.

Optional configuration

 flow meter, oiling machine, European standard manhole, pneumatic valve, AIP valve, anti overflow sensor plug, oil and gas recovery system, divided into several compartments.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
