GVW                                                Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

82

Power(Kw)

60

Wheelbase

3300

Front/Rear Suspension

1032/1642

Steering

Power steering

Approach/departure angle

18/13

Wheels & tire

7.0R16

Tire number

6+1

Tank Dimensions(mm)

3400×1600×1100

Cubage (m3)

5

Steel thickness of tank(mm)

4

RHD or LHD

optional

Overall Dimensions(mm)

5995×2000×2350

Curb weight (Kg)

3000

Engine

Model

CY4100Q

Horsepower

82

Maximum output Kw

60

Maximum torque N.m

/

Type

4 cylinders, in-line,4-stroke,water-cooled,diesel engine

Displacement

3.7L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Sprinkling width

14m each side

Suction height

7m

Standard configuration

carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
