GVW                                                 Driving Type 4x2

Model

CLW

Cab

A row and a half cab(with sleeping berth),allowable 3 passengers

Engine(Hp)

170

Power(Kw)

125

Wheelbase

3950

Front/Rear Suspension

1250/2100

Steering

Power steering

Approach/departure angle

23/12

Wheels & tire

9.0-20

Tire number

6+1

Tank Dimensions(mm)

4500×2200×1400

Cubage (m3)

10

Steel thickness of tank(mm)

5

RHD or LHD

optional

Overall Dimensions(mm)

7300×2500×2800

Curb weight (Kg)

5500

Engine

Model

B170 33

Horsepower

170

Maximum output Kw

125

Maximum torque N.m

560

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

5.900L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

3.6T

Rear Axle

9T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel, stainless steel, aluminum, etc. alloy, etc.

Standard configuration

oil pump,flow valves, tool box, manhole, climbing ladder, fire extinguisher, oil hose.

Optional configuration

 flow meter, oiling machine, European standard manhole, pneumatic valve, AIP valve, anti overflow sensor plug, oil and gas recovery system, divided into several compartments.

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
