GVW                                                Driving Type 4x2

Model

CLW

Cab

Single row cab, tilted

Engine(Hp)

140

Power(Kw)

103

Wheelbase

3800

Front/Rear Suspension

1180/2020

Steering

Power steering

Approach/departure angle

19/10

Wheels & tire

7.5R16

Tire number

6+1

Tank Dimensions(mm)

4800x2000x1300

Cubage (m3)

8

Steel thickness of tank(mm)

RHD or LHD

optional

Overall Dimensions(mm)

7000×2200×2800

Curb weight (Kg)

4200

Engine

Model

B140 33

Horsepower

140

Maximum output Kw

103

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3.9L

Cummins brand, Euro 3

Driving passenger

3

Transmission

WLY 6 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Standard configuration

oil pump, tool box, European standard manhole sub-sea valve, climbing ladder, fire extinguisher, oil hose.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
