GVW                                                  Driving Type 4x2

Model

CLW

Cab

Single row cab, tilted

Engine(Hp)

82

Power(Kw)

60

Wheelbase

3300

Front/Rear Suspension

1032/1658

Steering

Power steering

Approach/departure angle

17/15

Wheels & tire

7.0R16

Tire number

6+1

Tank Dimensions(mm)

4000x1750x1150

Cubage (m3)

5

Steel thickness of tank(mm)

4

RHD or LHD

optional

Overall Dimensions(mm)

5990×1980×2350

Curb weight (Kg)

3300

Engine

Model

CY4100Q

Horsepower

82

Maximum output Kw

60

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

3.7L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

five speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Standard configuration

oil pump, tool box, European standard manhole sub-sea valve, climbing ladder, fire extinguisher, oil hose.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
