GVW                                                  Driving Type 4x2

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

266

Power(Kw)

196

Wheelbase

5600

Front/Rear Suspension

1500/3370

Steering

Power steering

Approach/departure angle

16/19

Wheels & tire

295/80R22.5

Tire number

6+1

crane capacity(kg)

8000

Plate dimension(mm)

6500x2500

RHD or LHD

optional

Overall Dimensions(mm)

10500×2500×3800

Curb weight (Kg)

10900

Engine

Model

WD615.62

Horsepower

266

Maximum output Kw

196

Maximum torque N.m

1100

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9.726L

Sinotruk brand, Euro 2

Driving passenger

2

Transmission

HW13710,10 forwards,2 reverse , manual

Front Axle

HF7T

Rear Axle

ST16T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

8000kg

Lift capacity

8000kg

Platform

6.5x2.5m

Steel wire rope

25m

Standard configuration

 2 units of towing wheel, 1 unit of 8 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp.

Optional configuration

Flexible tail plate

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
