GVW                                                   Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

140

Power(Kw)

103

Wheelbase

3800

Front/Rear Suspension

1180/1715

Steering

Power steering

Approach/departure angle

20/14

Wheels & tire

7.5R16,8.25-16

Tire number

6+1

Tank Dimensions(mm)

4200×1900×1250

Cubage (m3)

8

Steel thickness of tank(mm)

4

RHD or LHD

optional

Overall Dimensions(mm)

7000×2300×2400

Curb weight (Kg)

4755

Engine

Model

B140 33

Horsepower

140

Maximum output Kw

103

Maximum torque N.m

502

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3.9L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

6 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.5T

Brake System

air brake

exhaust brake

Color and LOGO

customized

Electric system

24V

Tank material

Carbon steel

Sprinkling width

14m each side

Suction height

7m

Standard configuration

carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.

Delivery date

Within 20 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
