GVW                                                 Driving Type 4x2

Model

CLW

Cab

SINOTRUK HW76 Lengthen cab, single bunk, new type seat, adjustable steering wheel ,EURO new type heating & ventilating system, German VDO instruments, safety belts, exterior sun visor, stereo radio/cassette recorder, air conditioner

Engine(Hp)

266

Power(Kw)

196

Wheelbase

5600

Front/Rear Suspension

1500/2020

Steering

Power steering

Approach/departure angle

16/18

Wheels & tire

295/80/22.5

Tire number

6+1

Loading capacity(kg)

Plate dimension(mm)

/

RHD or LHD

optional

Overall Dimensions(mm)

8900×2500×3150

Curb weight (Kg)

14200

Engine

Model

WD615.62

Horsepower

266

Maximum output Kw

196

Maximum torque N.m

1100

Type

6 cylinders, in-line,4-stroke, diesel engine

Displacement

9.726L

SINOTRUK brand, Euro 2

Driving passenger

2

Transmission

HW13710,10 forwards,2 reverse,manual

Front Axle

HF7

Rear Axle

ST16

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

8000kg x2

Max lifting capacity

16000kg

Max towing capacity

30000kg

Steel wire rope

35m

Standard configuration

2 unit of 8 ton winch, 1 unit of steel wire rope, with four sets of steel forks, a set of forks cover, a set of steel ear lifting forks, a set of tires. A long row of engineering lights. A set of auxiliary lights, a set of auxiliary air pipe assemblies 1 unit of spare tire, 1 unit of jack, famous hydraulic system, crane and others

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
