GVW                                                  Driving Type 8x4

Model

CLW

Cab

SHACMAN F3000 four-point hydraulic suspension cab,electric automatic constant temperature air conditioner,power window,ordinary air filter,central lock,hydraulic major seat,tilt,metal bumper

Engine(Hp)

380

Power(Kw)

280

Wheelbase

1800+4575+1400

Front/Rear Suspension

1525/2150

Steering

Power steering

Approach/departure angle

18/13

Wheels & tire

12.00R20

Tire number

12+1

Loading capacity(kg)

Plate dimension(mm)

/

RHD or LHD

optional

Overall Dimensions(mm)

11500×2500×3300

Curb weight (Kg)

22300

Engine

Model

WP10.380E32

Horsepower

380

Maximum output Kw

280

Maximum torque N.m

1600

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9.726L

Weichai brand, Euro 3

Driving passenger

2,3

Transmission

FAST 10 forwards 2 reserves ,manual

Front Axle

7.5Tx2 ,MAN level

Rear Axle

13T x2,MAN level

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

10000kg x2

Max lifting capacity

20000kg

Max towing capacity

50000kg

Steel wire rope

45m

Standard configuration

2 unit of 10 ton winch, 1 unit of steel wire rope, with four sets of steel forks, a set of forks cover, a set of steel ear lifting forks, a set of tires. A long row of engineering lights. A set of auxiliary lights, a set of auxiliary air pipe assemblies 1 unit of spare tire, 1 unit of jack, famous hydraulic system, crane and others

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
