GVW                                                  Driving Type 4x2

Model

CLW

Cab

SHACMAN F3000 four-point hydraulic suspension cab,electric automatic constant temperature air conditioner,power window,ordinary air filter,central lock,hydraulic major seat,tilt,metal bumper

Engine(Hp)

300

Power(Kw)

221

Wheelbase

4600

Front/Rear Suspension

1525/1820

Steering

Power steering

Approach/departure angle

16/8

Wheels & tire

12.00R22.5

Tire number

10+1

Loading capacity(kg)

Plate dimension(mm)

/

RHD or LHD

optional

Overall Dimensions(mm)

9000×2500×3200

Curb weight (Kg)

15000

Engine

Model

WP10.300E22

Horsepower

300

Maximum output Kw

221

Maximum torque N.m

Type

6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

9.726L

Weichai brand, Euro 2

Driving passenger

2,3

Transmission

FAST 9 forwards 1 reserves ,manual

Front Axle

7.5T

Rear Axle

13T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

8000kg x2

Max lifting capacity

12000kg

Max towing capacity

20000kg

Steel wire rope

35m

Standard configuration

2 unit of 8 ton winch, 1 unit of steel wire rope, with four sets of steel forks, a set of forks cover, a set of steel ear lifting forks, a set of tires. A long row of engineering lights. A set of auxiliary lights, a set of auxiliary air pipe assemblies 1 unit of spare tire, 1 unit of jack, famous hydraulic system, crane and others

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
