GVW                                                  Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

98

Power(Kw)

72

Wheelbase

3360

Front/Rear Suspension

1015/1020

Steering

Power steering

Approach/departure angle

24/21

Wheels & tire

7.0R16

Tire number

6+1

Loading capacity(kg)

Plate dimension(mm)

/

RHD or LHD

LHD

Overall Dimensions(mm)

5400×2000×2300

Curb weight (Kg)

3815

Engine

Model

4KH1CN5LS

Horsepower

98

Maximum output Kw

72

Maximum torque N.m

220

Type

4 cylinders, in-line,4-stroke, diesel engine

Displacement

2.999L

ISUZU brand, Euro 5

Driving passenger

2,3

Transmission

ISUZU MSB 5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4.8T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

4000kg

Max lifting capacity

3000kg

Max towing capacity

5000kg

Steel wire rope

21m

Standard configuration

1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, famous hydraulic system, crane and others

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
