GVW                                                   Driving Type 6x4

Model

CLW

Cab

Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers

Engine(Hp)

260

Power(Kw)

191

Wheelbase

4350+1300

Front/Rear Suspension

1460/2340

Steering

Power steering

Approach/departure angle

20/14

Wheels & tire

10.00R20

Tire number

10+1

Loading capacity(kg)

Plate dimension(mm)

/

RHD or LHD

optional

Overall Dimensions(mm)

9500×2500×3150

Curb weight (Kg)

19400

Engine

Model

C260 33

Horsepower

260

Maximum output Kw

191

Maximum torque N.m

1090

Type

6 cylinders, in-line,4-stroke,turbo inter-cooling, diesel engine

Displacement

8.3L

Cummins brand, Euro 3

Driving passenger

2,3

Transmission

10 speed forward and 2 reverse, manual

Front Axle

5T

Rear Axle

10Tx2

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

10000kg x2

Max lifting capacity

20000kg

Max towing capacity

40000kg

Steel wire rope

45m

Standard configuration

2 unit of 10 ton winch, 1 unit of steel wire rope, with four sets of steel forks, a set of forks cover, a set of steel ear lifting forks, a set of tires. A long row of engineering lights. A set of auxiliary lights, a set of auxiliary air pipe assemblies 1 unit of spare tire, 1 unit of jack, famous hydraulic system, crane and others

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
