GVW                                                    Driving Type 4x2

Model

CLW

Cab

Howo single row cab, air con ,allowable 3 passengers

Engine(Hp)

116

Power(Kw)

86

Wheelbase

3800

Front/Rear Suspension

1160/1955

Steering

Power steering

Approach/departure angle

27/22

Wheels & tire

7.5R16

Tire number

6+1

Tank Dimensions(mm)

/

Cubage (m3)

7

RHD or LHD

optional

Overall Dimensions(mm)

7000×2200×2900

Curb weight (Kg)

4200

Engine

Model

YN4102QBZL

Horsepower

116

Maximum output Kw

86

Maximum torque N.m

/

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

3.76L

Yunnei brand, Euro 2

Driving passenger

3

Transmission

WLY 6 speed forward and one reverse, manual

Front Axle

2.4T

Rear Axle

4.2T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Fire equipment part

Fire pump

CB10/30 , rated pressure 1.0MPa, flow 30L/s

Fire gun

PS30 , flow 30L/s , jet distance ≥30m

Standard configuration

national standard equipment box, full units national standard fire-fighting equipment, fire pump, fire gun,fire power take off, sliding gate, row type lights, reel, common tools ,rear climbing ladder, water tank.

Optional configuration

foam type, dry powder type, stainless tank, other requirements.

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
