GVW                                                 Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

82

Power(Kw)

60

Wheelbase

3300

Front/Rear Suspension

1032/1658

Steering

Power steering

Approach/departure angle

19/15

Wheels & tire

7.0R16

Tire number

6+1

Loading capacity(kg)

/

Plate dimension(mm)

/

RHD or LHD

optional

Overall Dimensions(mm)

5995×2000×2250

Curb weight (Kg)

4800

Engine

Model

CY4100Q

Horsepower

82

Maximum output Kw

60

Maximum torque N.m

Type

4 cylinders, in-line,4-stroke,diesel engine

Displacement

3.7L

Chaoyang brand, Euro 2

Driving passenger

2,3

Transmission

5 speed forward and one reverse, manual

Front Axle

2T

Rear Axle

4T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

4000kg

Max lift capacity

3000kg

Max towing capacity

5000kg

Steel wire rope

21m

Standard configuration

1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, famous hydraulic system, crane and others

Delivery date

Within 30 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
