GVW                                                 Driving Type 4x2

Model

CLW

Cab

Foton Auman M one and half row cab, tilted

Engine(Hp)

240

Power(Kw)

177

Wheelbase

5750

Front/Rear Suspension

1270/3500

Steering

Power steering

Approach/departure angle

20/10

Wheels & tire

11R22.5

Tire number

6+1

Loading capacity(kg)

8000

Plate dimension(mm)

9600(8400+1200)x2500

RHD or LHD

LHD

Overall Dimensions(mm)

10520×2525×3000

Curb weight (Kg)

11000

Engine

Model

YC6A240-33

Horsepower

240

Maximum output Kw

177

Maximum torque N.m

900

Type

6 cylinders, in-line,4-stroke,turbo diesel engine

Displacement

7.255L

Yuchai brand, Euro 3

Driving passenger

2,3

Transmission

8 speed forward and one reverse, manual

Front Axle

5.5T

Rear Axle

10T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

8000

Lift capacity

8000

Platform

9.4x2.5m

Steel wire rope

25m

Standard configuration

 2 units of towing wheel, 1 unit of 8ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp.

Optional configuration

Flexible tail plate

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
