GVW                                                 Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

191

Power(Kw)

141

Wheelbase

4475

Front/Rear Suspension

1110/2900

Steering

Power steering

Approach/departure angle

17/11

Wheels & tire

235/75R17.5

Tire number

6+1

Loading capacity(kg)

5000

Plate dimension(mm)

6200×2400

RHD or LHD

LHD

Overall Dimensions(mm)

8500×2500×2550

Curb weight (Kg)

5700

Engine

Model

4HK1-TC51

Horsepower

191

Maximum output Kw

141

Maximum torque N.m

510

Type

4 cylinders, in-line,turbo ,diesel engine

Displacement

5.193L

ISUZU brand, Euro 5

Driving passenger

3

Transmission

ISUZU MLD 6 speed forward and one reverse, manual

Front Axle

4T

Rear Axle

7T

Brake System

air brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

5000kg

Lift capacity

3500kg

Platform

6200×2300mm

Steel wire rope

25m

Standard configuration

 2 units of towing wheel, 1 unit of 5 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp.

Optional configuration

Flexible tail plate

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
