GVW                                                  Driving Type 4x2

Model

CLW

Cab

One row cab, tilted

Engine(Hp)

130

Power(Kw)

96

Wheelbase

3815

Front/Rear Suspension

1015/2450

Steering

Power steering

Approach/departure angle

24/9

Wheels & tire

7.0R16

Tire number

6+1

Loading capacity(kg)

4000

Plate dimension(mm)

5600×2300

RHD or LHD

LHD

Overall Dimensions(mm)

7500×2400×2400

Curb weight (Kg)

4280

Engine

Model

4KH1CN5HS

Horsepower

130

Maximum output Kw

96

Maximum torque N.m

290

Type

4 cylinders, in-line diesel engine

Displacement

2.999L

ISUZU brand, Euro 5

Driving passenger

2

Transmission

ISUZU MSB 5 speed forward and one reverse, manual

Front Axle

2.5T

Rear Axle

4.8T

Brake System

oil brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

4000kg

Lift capacity

3000kg

Platform

5600×2300mm

Steel wire rope

21m

Standard configuration

 2 units of towing wheel, 1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp.

Optional configuration

Flexible tail plate

Delivery date

Within 40 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
