GVW                                                 Driving Type 4x2

Model

CLW

Cab

Howo light duty cab ,one row cab, tilted

Engine(Hp)

116

Power(Kw)

85

Wheelbase

3800

Front/Rear Suspension

1160/2470

Steering

Power steering

Approach/departure angle

18/11

Wheels & tire

7.5R16

Tire number

6+1

Loading capacity(kg)

4000

Plate dimension(mm)

5600×2300

RHD or LHD

optional

Overall Dimensions(mm)

7500×2300×2500

Curb weight (Kg)

5100

Engine

Model

YN4102QBZL

Horsepower

116

Maximum output Kw

85

Maximum torque N.m

290

Type

4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Displacement

3.76L

Yunnei brand, Euro 2

Driving passenger

2

Transmission

6 speed forward and one reverse, manual

Front Axle

2.4T

Rear Axle

4.2T

Brake System

air brake  ,exhaust brake

Color and LOGO

customized

Electric system

24V

Major parameter

Winch capacity

4000kg

Lift capacity

3000kg

Platform

5600×2300mm

Steel wire rope

21m

Standard configuration

 2 units of towing wheel, 1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp.

Optional configuration

Flexible tail plate

Delivery date

Within 60 days after receipt advance

Packing

Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
