Regular maintenance of compressed garbage trucks can give full play to the technical performance and benefits of compressed garbage trucks, but also to extend their service life, the following compressed garbage truck manufacturer for you to introduce the compressed garbage truck maintenance methods:
Compressed garbage truck chassis and engine maintenance: compressed garbage truck chassis and engine part of the car company in accordance with the chassis and engine instruction manual for maintenance, check the engine oil level, coolant level, add when necessary. After starting the engine, observe and listen to whether its operation is normal, check the automobile instrumentation, lights, parking brake, parking brake, steering system and the power take-off is normal.
Maintenance of compressed garbage truck: rinse the body after daily operation, wipe the glass and mirrors; rinse the inside of the garbage tank, filler and sewage tank, remove residual garbage, do not spray water directly to the electrical components and fuel tank intake holes when washing the car. Clean the sealing joint surfaces to ensure good sealing, and at the same time avoid damaging the rubber seals and gaskets due to sharp or hard objects in the garbage. Check the hydraulic oil tank level height, the oil tank oil level shall not be lower than the minimum height shown in the oil mark, oil is not enough to refueling supplement. Check method: push shovel cylinder, skateboard cylinder in full retraction position, scraper cylinder in full extension position, filler in the closed state. Note: The hydraulic oil must be added in the empty filter port on the hydraulic oil tank. Hydraulic oil must be clean and non-polluting, the grade can be YB-N46 anti-wear hydraulic oil, the environmental oil degree is lower than 5 ℃, it is recommended to use the grade for the YC-N46D low-temperature hydraulic oil.
Check the operation device maneuvering, electric control buttons and sensors, if there is any problem, it should be adjusted or replaced in time.
Check the whole vehicle for oil seepage, water leakage and air leakage.
Check whether the tire nuts, bolts, nuts and pins of each department are loose; check the appearance and air pressure of tires.
Troubleshoot any faults that occurred on the same day. First-level maintenance, carried out every 50 hours of operation.
The first level of maintenance focuses on lubrication and tightening, and in addition to performing routine maintenance items, the following inspections should be performed. Clean the engine fuel filter, air filter, oil filter, hydraulic system air filter. Add grease to the oil nozzles at each hinge point, and apply grease to the surface of the chute in the dumpster and filler. Check the tightness of the coupling, check the connection between the dumpster and the frame, the push shovel slider seat and the push shovel, the hinge shaft of the filler slider, and the connection of the pins of each cylinder, and tighten them if necessary.
The second level of maintenance is carried out every 250 hours of operation, and the second level of maintenance focuses on inspection and adjustment. Perform all items of the first level maintenance. Check the pressure of each pressure valve in the hydraulic system, if there is any deviation, it should be adjusted in time (carried out by professional personnel); clean the suction oil filter element of the hydraulic system, check the return oil filter pressure, when the return oil filter pressure pointer reaches 0.08MPa, it should be replaced in time for the return oil filter element assembly (for one-time use); check the connectors and sealing surfaces of the joint sealing situation; find that the high-pressure hose has cracks, local damage and aging and expansion, etc. It should be replaced in time when it is found. The high-pressure hose should be replaced in time when cracks, partial damage and aging and swelling are found.
Check whether there is any blockage of filter and cracking and aging of air hose in the air circuit system, and replace them if necessary. Check the rubber sealing strip on the joint surface between the dumpster and the filler and the rubber gasket of the drain valve, and replace them if necessary. Check the wear and tear of the shovel slider and filler slider, as well as the pins and bushings, and replace them if necessary. Check the welds of each assembly for cracking and desoldering, plastic deformation of the structure, and cracks in the pins. Problems found should be eliminated in time. Check the pressure filling cycle and unloading time, if it is too fast or too slow should be adjusted to the normal state.
Tertiary maintenance, performed every 1,000 hours of operation Tertiary maintenance focuses on partial assembly disassembly, cleaning, inspection, adjustment and elimination of hidden problems. Carry out all the contents of the first level maintenance and the second level maintenance.
Check the condition of hydraulic fluid. If the hydraulic fluid is found to have more pollutants, turbid black, foam emulsification and viscosity changes, etc., the hydraulic fluid must be replaced. Note: When replacing the hydraulic oil, the push shovel cylinder, lifting cylinder and skateboard oil is in full contraction state, the scraper cylinder is in full extension state, after the old oil is discharged, remove the coarse and fine oil filter in the oil tank, clean the coarse filter, oil drain screw and oil tank, and install it back after cleaning. Add clean hydraulic oil to the oil scale range, exhaust the air mixed in the pipeline. Exhaust process can start the engine running at idle, the power take-off gear, the oil pump for slow speed operation, one by one to open the hydraulic circuit at the highest place of the pipe connector nut to bleed. After exhausting the air tighten the nuts, there shall be no leakage. After replacing the oil, let the hydraulic system test run, that work normally.
